Texas Instruments TPS563203EVM Evaluation Module
Texas Instruments TPS563203EVM Evaluation Module offers an easy method to measure and evaluate the TPS563203 step-down converter in a SOT-563 package. The TPS563203EVM features a 3V to 17V input, 12V (nom), and supplies a 1.05V output at 3A. The TI TPS563203EVM Evaluation Module includes AC signal injection terminals for feedback-loop measurements.
Features
- 3V to 17V input voltage range
- 0.6V to 7V output voltage range
- Up to 3A output current
- ECO mode
- Fast transient response
Layout
Associated Eval Module
Texas Instruments TPS562203EVM Evaluation Module
Configured to evaluate the operation of the TPS562203 converter in a SOT563 package.
Videos
Related Product
Texas Instruments TPS56320x Synchronous Buck Converters
These are simple, easy-to-use 3A synchronous buck converters in a SOT-563 package.
